| Pin | T568A Pair | T568B Pair | Wire | T568A Color | T568B Color | |
|---|---|---|---|---|---|---|
| 1 | 3 | 2 | tip | white/green stripe | white/orange stripe | |
| 2 | 3 | 2 | ring | green solid | orange solid | |
| 3 | 2 | 3 | tip | white/orange stripe | white/green stripe | |
| 4 | 1 | 1 | ring | blue solid | blue solid | |
| 5 | 1 | 1 | tip | white/blue stripe | white/blue stripe | |
| 6 | 2 | 3 | ring | orange solid | green solid | |
| 7 | 4 | 4 | tip | white/brown stripe | white/brown stripe | |
| 8 | 4 | 4 | ring | brown solid | brown solid |
A regular patch cable (to link a host to a hub, router or wall jack) is made by wiring both ends of a Cat5 cable with same coloring chema. Either T568A or T568B.
A cross-link (crossover) patch cable is made by wiring the ends of a piece of Cat5 cable with opposite schemas. You crimp one end with T568A and another with T568B.
That's about all the secret. Cross-link patch cables are used for connecting a host directly to another bypassing hubs, routers or any other network equipment.
IEEE 802.11n is a proposed amendment to the IEEE 802.11-2007 wireless networking standard to significantly improve network throughput over previous standards, such as 802.11b and 802.11g, with many experts claiming that this wireless technology will finally allow consumers to move beyond traditional wired ethernet LANs.
IEEE 802.11n builds on previous 802.11 standards by adding multiple-input multiple-output (MIMO) and 40 MHz operation to the physical (PHY) layer. MIMO uses multiple transmitter and receiver antennas to improve the system performance. The 40 MHz operation uses wider bands, compared to 20 MHz bands in previous 802.11 operation, to support higher data rates. Wider bandwidth channels are cost effective and easily accomplished with moderate increases in digital signal processing.
If properly implemented, 40-MHz channels can provide greater than two times the usable channel bandwidth of two 802.11 legacy channels. Coupling MIMO architecture with wider bandwidth channels offers the opportunity of creating very powerful yet cost-effective approaches for increasing the physical transfer rate. MIMO can provide many benefits, all derived from the ability to process spatially different signals simultaneously. Two important benefits explored here are antenna diversity and spatial multiplexing. Using multiple antennas, MIMO technology offers the ability to coherently resolve information from multiple signal paths using spatially separated receive antennas.
Multipath signals are the reflected signals arriving at the receiver some time after the original or line of sight (LOS) signal has been received. Multipath is typically perceived as interference degrading a receiver's ability to recover the intelligent information. MIMO enables the opportunity to spatially resolve multipath signals, providing diversity gain that contributes to a receiver's ability to recover the intelligent information.
Another valuable opportunity MIMO technology may provide is Spatial Division Multiplexing (SDM). SDM spatially multiplexes multiple independent data streams, transferred simultaneously within one spectral channel of bandwidth. MIMO SDM can significantly increase data throughput as the number of resolved spatial data streams is increased. Each spatial stream requires its own TX/RX antenna pair at each end of the transmission. MIMO technology requires a separate radio frequency chain and analog-to-digital converter for each MIMO antenna. This increasing complexity ultimately translates to higher implementation costs as higher-performance systems are required.
A second technology being incorporated into 802.11n is channel bonding, which can use two separate non-overlapping channels at the same time to transmit data. This technique also increases the amount of data that can be transmitted. A third technology in 802.11n is called payload optimization or packet aggregation, which, in simple terms, means more data can be stuffed into each transmitted packet.
The transmitter and receiver use precoding and postcoding techniques, respectively, to achieve the capacity of a MIMO link. Precoding includes spatial beamforming and spatial coding, where spatial beamforming improves the received signal quality at the decoding stage. Spatial coding can increase data throughput via spatial multiplexing and increase range by exploiting the spatial diversity, through techniques such as Alamouti coding.
The number of simultaneous data streams is bounded from above by the minimum number of antennas in use on both sides of the link. However, the individual radios often further limit the number of spatial streams that may carry unique data. The
moniker helps identify what a given radio is capable of. The first number (a) is the maximum number of transmit antennas or RF chains that can be used by the radio. The second number (b) is the maximum number of receive antennas or RF chains that can be used by the radio. The third number (c) is the maximum number of data spatial streams the radio can use. For example, a radio that can transmit on two receive antennas, receive on three, but only send or receive two data streams would be 2x3:2.
The 802.11n draft allows up to 4x4:4. However, the Wi-Fi Alliance 802.11n Draft 2.0 certification only allows for two data spatial streams. Common configurations of Wi-Fi Alliance Draft 2.0 certified devices are 2x2:2, 2x3:2, and 3x3:2. All three configurations have the same maximum throughputs and features, and differ only in the amount of diversity the antenna systems provide.
The main medium access controller (MAC) feature that provides a performance improvement is aggregation. (Refer to a PPT presentation by IEEE, which shows the performance of the various 802.11n MAC features at the completed proposal stage. Since then, some of the details may have changed, but features and performance are essentially unchanged.) Two types of aggregation are defined:
Aggregation in the MAC is necessary to make the best use of the properties of the 802.11n PHY - i.e., while increasing the data rate, its overhead has also increased. A-MPDU aggregation requires the use of Block Acknowledgement or BlockAck, which was introduced in 802.11e and has been optimized in 802.11n. Reverse Direction is an optional feature of the 802.11n MAC that supports a bidirectional data flow given a single channel access.
When 802.11g was released to share the band with existing 802.11b devices, it had to provide ways of ensuring coexistence between the legacy and the new devices. Now 802.11n extends coexistence management to protect its transmissions from legacy devices, which include 802.11g, 802.11b and 802.11a.
802.11n has three differences in the type of protection it enables.
Even with protection, the increased throughput of 802.11n can cause large discrepancies between the throughput an 802.11n device can achieve when alone compared to what it can get when legacy devices are present. This is an extension of the 802.11b/802.11g coexistence problem.
Work on the 802.11n standard dates back to 2004. The draft is expected to be finalized in November 2008 with publication in July 2009, but major manufacturers are now releasing 'pre-N', 'draft n' or 'MIMO-based' products based on early specs. These vendors anticipate the final version will not be significantly different from the draft, and in a bid to get the early mover advantage, are pushing ahead with the technology. Depending on the manufacturer, a firmware update may eventually be able to make current "Draft-N" hardware compatible with the final version.
In late November 2007, work on the 802.11n standard slowed due to patent issues. The CSIRO holds the patent to a component of the 802.11n standard. This component is also part of 802.11a and 802.11g. The IEEE requested from the CSIRO a Letter of Assurance (LoA) that no lawsuits would be filed for anyone implementing the standard. The CSIRO responded that, as they were currently being sued by some of the companies who would be sheltered by the LoA, they could not provide one at this time without adversely impacting their defense in the lawsuits.
| Protocol | Release Date | Op. Frequency | Throughput (Typ) | Data Rate (Max) | Modulation Technique | Range (Radius Indoor)
Depends, # and type of walls |
Range (Radius Outdoor)
Loss includes one wall |
|---|---|---|---|---|---|---|---|
| Legacy | 1997 | 2.4 GHz | 0.9 Mbit/s | 2 Mbit/s | ~20 Meters | ~100 Meters | |
| 802.11a | 1999 | 5 GHz | 23 Mbit/s | 54 Mbit/s | OFDM | ~35 Meters | ~120 Meters |
| 802.11b | 1999 | 2.4 GHz | 4.3 Mbit/s | 11 Mbit/s | DSSS | ~38 Meters | ~140 Meters |
| 802.11g | 2003 | 2.4 GHz | 19 Mbit/s | 54 Mbit/s | OFDM | ~38 Meters | ~140 Meters |
| 802.11n | June 2009 (est.) |
2.4 GHz 5 GHz |
74 Mbit/s | 248 Mbit/s | ~70 Meters | ~250 Meters | |
| 802.11y | June 2008 (est.) |
3.7 GHz | 23 Mbit/s | 54 Mbit/s | ~50 Meters | ~5000 Meters |
